2W-500-50 2inch solenoid valve Brass Normally Closed 2/2way water Valve AC220VDC24V
| 2W Series 2/2 way Direct Acting Solenoid Valve |
| Model | 2W025-06 | 2W025-08 | 2W040-10 | 2WH012-06 | 2WH012-08 | 2WH020-10 |
| Medium | Air,Water,Oil,Gas |
| Operation | Direct Acting |
| Type | Normal Close |
| Orifice Size(mm) | 2.5 | 4 | 1.2 | 2 |
| CV Value | 0.23 | 0.6 | 0.05 | 0.15 |
| Port Size | G1/8" | G1/4" | G3/8" | G1/8" | G1/4" | G3/8" |
| Operation Fluid Viscosity | Below 23 CST |
| Operating Pressure | Air,Water,Oil,Gas:0~0.7Mpa | Air,Water,Oil,Gas:0~0.2Mpa |
| Max Pressure Resistance | 1.0MPa | 3.5MPa |
| Operating Temperature | NBR for -5~80°C and fluororubber for -5~80°C |
| Voltage Range | ±10% |
| Material of Body | Stainless Steel or Brass |
| Material of Oil Seal | NBR,EPDM or fluororubber |
2W series small oriffice Fluid Control Valve, also known zero-pressure solenoid valve, the initial state for normally closed,normally open only available for below 3/8", thread size range from 1/8" to 3/8", Din connector type and flying leads type,anti-explosion and anti-water coil are available. With the stalbe quality and wide application, 2W valve is popular with customers, especially in the water treatment system, the 2W valve is used widely.
Materials:
| PARTS | MATERIAL |
| Body | Cast Bronze/ Forge Brass/Zinc Alloy |
| Coil | Special Copper Wire (H) |
| Core | Stainless Steel |
| Tube | Stainless Steel |
| Spring | Stainless Steel |
| Plug | NBR.fluororubber .Silicon, PTFE |
| Diaphragm | NBR.fluororubber .Silicon
|
FAQ
1. When your company establish?
Ningbo Fly Automation Co.,Ltd Was established in 2010, we have been working in agrochemical field for about 26 years, we have a professional production of process, committed to providing customers with the most satisfactory service.
2. Are you a trader or manufacturer? Do you have factory?
We are a solenoid valve manufacturer, we have the ability of mass production . we have our own developing and designing team, which ensure our own technological and specific products for customers.
3. Where’s your factory located? Can we visit your factory?
Our company is in Xikou town,Fenghua city,Zhejiang Province, China,Which is near by Ningbo city,
Customers will be always welcomed to visit our company and our factories.Please contact us your schedule,we will arrange to pick up you and visit our factory.
4. How do you make the quality guarantee?
We have our own quality control center, we have advanced equipments for the inspections. We can guarantee every product will be tested after production.
5. Can you support the specific productions?
We can design and develop the products of customer's requirement, if you have the specific products, please send us a sample, we will develop it for you.
6. What's the transportation service?
Usually, we will be according your address, choose the fastest and cheapest way, the DHL,TNT,Fedex or China post express all can support.
Our service
One year quality guarantee Policy
We will check the goods quality before shipment. If there are some unexpected problems
happen, we hope to solve the problems with buyer through friendly in the following ways:
1, If it is quality problem, buyer can submit argue within 15days after receiving the goods,
buyer must provide photos or video and other evidence to seller for identify.
2, Man-made damaged, buyers take full responsibility.
3, Product quality processing program:
1) The buyer return the products for bad quality reasons for one year (not included those
damages coursed by shipping or Man-made damaged ). A 15% restocking fee is
assessed for any products returned in "used" condition. And then we will send a new
product to buyer and pay for the resend shipping cost.
2) If the goods (total price including shipping is less than 10USD) has quality problems, we
will resend a new product in buyer next order; if buyer don’t plan to make a new order in
the near term, buyer can pay the resend shipping cost and ask to resend a new product. If
there is an issue with the products, please contact us– we will solve it as soon as we get
your email.
