FESTO Rod clevis SG-M16X1,5 6146 GTIN4052568001100 Pneumatic Air Cylinders
About product
1.Easy installation
2.Precision machining
3.Compact structure
4.Multilayer grinding process
5.High strength, low vibration, compact and durable
Product Technical Data
| Size | M16x1.5 |
| Conforms to standard | DIN 71752 ISO 8140 |
| Threaded connection | Female thread M16x1.5 |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Suitability for the production of Li-ion batteries | Metals with more than 1% copper by mass are excluded from use. Exceptions are printed circuit boards, cables, electrical plug connectors and coils |
| Ambient temperature | -40°C-150°C |
| Product weight | 375 g |
| Note on materials | RoHS-compliant |
| Material bolt | Steel Galvanised |
| Material clevis | Steel Galvanised |
| Material nut | Steel Galvanised |
Another size as below
| Type | Part no. | Weight(g) | GTIN | Price |
| SG-M4 | 6532 | 10 | 4052568001278 | USD8-15 |
| SG-M6 | 3110 | 22 | 4052568000363 | USD8-15 |
| SG-M8 | 3111 | 53 | 4052568000370 | USD8-15 |
| SG-M10x1.25 | 6144 | 103 | 4052568001087 | USD10-20 |
| SG-M12x1.25 | 6145 | 166 | 4052568001094 | USD10-20 |
| SG-M16x1.5 | 6146 | 375 | 4052568001100 | USD10-20 |
Rod clevis SG
Scope of delivery: 1 rod clevis, 1 clevis pin, 1 hex nut (M4: DIN 934, M6 ... M16: DIN 439)
Material: Galvanised steel Free of copper and PTFE RoHS-compliant
Delivery
1. If the products we have in store, we will send it out ASAP after payment.
2. If the products which were customized, we will complete the production within a specified period of time, and send it out the first time, we can promise it.
3. Also we can send by your delivery acount if you want.
4. We have a variety of ways to send goods, usually DHL, Fedex, TNT will be normal ways. If you require use of a courier, we can do it.
There are many specifications of connectors, price and delivery time. Welcome to inquire.
