FESTO Swivel flange SNCS-80 174401 GTIN 4052568004866 Pneumatic Air Cylinders
About product
1.Material: Wrought aluminium alloy
2.Moderate corrosion stress.
3.Indoor applications in which condensation can occur. External visible parts with primarily decorative surface requirements which are in direct contact with a normal industrial environment.
4.The specifications are complete. I have everything you want.
5.Easy installation,precision machining,compact structure.
Product Technical Data
| Size | 80 |
| Based on standard | ISO 15552 (previously also VDMA 24562, ISO 6431, NF E49 003.1, UNI 10290) |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Ambient temperature | -40°C-150°C |
| Product weight | 557 g |
| Note on materials | RoHS-compliant |
| Material mounting | Die-cast aluminium |
| Material rod end bearing | Steel PTFE |
| Material screws | Steel Galvanised |
Another size as follow
| Type | Order no | GTIN | Weihght | Price |
| SNCS-32 | 174397 | 4052568014063 | 86 | USD20-30 |
| SNCS-40 | 174398 | 4052568014070 | 122 | USD20-30 |
| SNCS-50 | 174399 | 4052568014087 | 216 | USD30-40 |
| SNCS-63 | 174400 | 4052568014094 | 281 | USD30-40 |
| SNCS-80 | 174401 | 4052568004866 | 557 | USD40-50 |
Product photo about SNCS series
Competitive Advantage
Our product features: Our Services Guarantee:
1) Competitive price 1) Prompt respond (Reply with 24 hours)
2) Good quality 2) Free Samples (Customer pay for the delivery cost)
3) Professional Packaging, 3) Registration support.
4) Produce according to Customers’ instruction 4) Photos/videos are available during production.
5) None delay shipment
5) Loading inspection, and send loading photos before shipment.
There are many specifications of connectors, price and delivery time. Welcome to inquire.
