Mini Slide Pneumatic Air Cylinders DGST-20-100-E1A 8078868 GTIN4052568446994

Name: Mini Slide Pneumatic Air Cylinders DGST20100E1A 8078868 GTIN4052568446994
Brand: FESTO
Price: 1 USD

Quality Mini Slide Pneumatic Air Cylinders DGST-20-100-E1A 8078868 GTIN4052568446994 wholesale

Brand Name : FESTO

Model Number : DGST-20-100-E1A

Place of Origin : China

MOQ : 1pc

Price : EXW USD500-550

Payment Terms : T/T, Western Union, Paypal

Supply Ability : 20 pcs per month

Delivery Time : 10-15working days

Packaging Details : Plastic bag, Carton

Type : DGST-20-100-E1A

Part no : 8078868

Brand : FESTO

GTIN : 4052568446994

Max. speed : 0.5 m/s

Repetition accuracy : <= 0.3 mm

Contact Now

FESTO Mini slide DGST-20-100-E1A 8078868 GTIN4052568446994 Pneumatic Air Cylinders

Advantage

1.Space-saving mounting of mini-slides next to one another.

2.The connection kit enables having axial supply ports.

3.Particularly suitable for applications in which no space is available at the side for supply ports.

4.No readjustment required; position is fully maintained under lock and load.

5.Stroke can be reduced to the next smaller standard stroke.

6.Fast and simple adjustment using two tools.

Technical Data

Stroke	100 mm
Piston diameter	20 mm
Operating mode, drive unit	Yoke
Cushioning	Elastomer cushioning, double-sided, stroke not adjustable
Mounting position	optional
Guide	Ball bearing cage guide
Design	Twin piston Yoke Piston rod Slide
Position detection	Via proximity switch
Symbol	00991249
Max. speed	0.5 m/s
Repetition accuracy	<= 0.3 mm
Mode of operation	Double-acting
Corrosion resistance class CRC	1 - Low corrosion stress
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Ambient temperature	-10°C-60°C
Cushioning length	1 mm
Product weight	1962 g
Type of mounting	With through-hole
Pneumatic connection	G1/8
Note on materials	RoHS-compliant
Material cover	Wrought aluminium alloy
Material seals	HNBR
Material guide	POM TPE-E High-alloy steel
Material housing	Wrought aluminium alloy
Material piston rod	High-alloy stainless steel

Other size as follow

Type	Order no	Weight(g)	Price
DGST-20-10-E1A	8078862	978	USD500-550
DGST-20-20-E1A	8078863	986	USD500-550
DGST-20-30-E1A	8078864	994	USD500-550
DGST-20-40-E1A	8078865	1055	USD500-550
DGST-20-50-E1A	8078866	1196	USD500-550
DGST-20-80-E1A	8078867	1618	USD500-550
DGST-20-100-E1A	8078868	1962	USD500-550

Dimensions

Mini Slide Pneumatic Air Cylinders DGST-20-100-E1A 8078868 GTIN4052568446994

A wide range of products with excellent prices. Please hurry to me!
