Compact Pneumatic Air Cylinders ADNGF-40-50-P-A 554255 GTIN4052568198800

Product Categories
FLY AUTOMATION
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Compact Pneumatic Air Cylinders ADNGF-40-50-P-A 554255 GTIN4052568198800

  • 1
  • 2
  • 3

Brand Name : FESTO

Model Number : ADNGF-40-50-P-A

Place of Origin : China

MOQ : 1pc

Price : EXW USD60-80

Payment Terms : T/T, Western Union, Paypal

Supply Ability : 80 pcs per month

Delivery Time : 10-15working days

Packaging Details : Plastic bag, Carton，OPP bag

Type : ADNGF-40-50-P-A

Brand : FESTO

Part no : 554255

GTIN : 4052568198800

Stroke : 50 mm

Piston diameter : 40 mm

Contact Now

FESTO Compact cylinder ADNGF-40-50-P-A 554255 GTIN4052568198800 Pneumatic Air Cylinders

About product

1.Time-saving,No adjustment required.

2.Small cushioning capacity ,Low speeds, Small loads.

3.The drive has elastic polymer flexible end-position cushioning.

4.Cushioning P.

Technical Data

Stroke 50 mm
Piston diameter 40 mm
Based on standard ISO 21287
Cushioning Elastic cushioning rings/plates at both ends
Mounting position optional
Design Piston Piston rod Profile barrel
Position detection Via proximity switch
Protection against torque/guide Guide rod with yoke
Mode of operation Double-acting
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Ambient temperature -20°C-80°C
Basic weight for 0 mm stroke 430 g
Additional weight per 10 mm stroke 45 g
Pneumatic connection G1/8
Note on materials RoHS-compliant
Material cover Aluminium Anodised
Material seals TPE-U(PUR)
Material piston rod High-alloy steel
Material cylinder barrel Wrought aluminium alloy Smooth anodised

Other size as below

Type Order no Weight(g) Price
ADNGF-40-5-P-A 554248 453 USD60-80
ADNGF-40-10-P-A 554249 475 USD60-80
ADNGF-40-15-P-A 554250 498 USD60-80
ADNGF-40-20-P-A 554251 520 USD60-80
ADNGF-40-25-P-A 554252 543 USD60-80
ADNGF-40-30-P-A 554253 565 USD60-80
ADNGF-40-40-P-A 554254 610 USD60-80
ADNGF-40-50-P-A 554255 655 USD60-80
ADNGF-40-60-P-A 554256 700 USD60-80
ADNGF-40-80-P-A 554257 790 USD60-80

Type codes

Compact Pneumatic Air Cylinders ADNGF-40-50-P-A 554255 GTIN4052568198800
