4154769 Pneumatic Air Cylinders Guided Drive DFM-10-10-P-A-GF GTIN 4052568418052

  • 1
  • 2

Brand Name : FESTO

Model Number : DFM-10-10-P-A-GF

Place of Origin : China

MOQ : 1pc

Price : EXW USD40-50

Payment Terms : T/T, Western Union, Paypal

Supply Ability : 80 pcs per month

Delivery Time : 10-15working days

Packaging Details : Plastic bag, Carton，OPP bag

Brand : FESTO

Part no : 4154769

Type : DFM-10-10-P-A-GF

GTIN : 4052568418052

Max. speed : 1.7 m/s

Mode of operation : Double-acting

Contact Now

FESTO Guided drive DFM-10-10-P-A-GF 4154769 GTIN 4052568418052 Pneumatic Air Cylinders

Advantage

1.Minimal space requirement.

2.Minimal mounting time.

3.Choice of compressed air supply ports.

4.Wide range of mounting options.

5.Good protection against torsion.

Technical Data

Stroke 10 mm
Piston diameter 10 mm
Operating mode, drive unit Yoke
Cushioning Elastic cushioning rings/plates at both ends
Mounting position optional
Guide Plain-bearing guide
Design Guidance
Position detection Via proximity switch
Symbol 00991737
Max. speed 1.7 m/s
Mode of operation Double-acting
Corrosion resistance class CRC 1 - Low corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Ambient temperature -10°C-60°C
Product weight 45.5 g
Pneumatic connection M3
Note on materials RoHS-compliant
Material cover High-alloy stainless steel
Material seals NBR
Material dynamic seals HNBR
Material end plate Anodised wrought aluminium alloy
Material guide rod High-alloy stainless steel
Material housing Anodised wrought aluminium alloy
Material piston rod High-alloy stainless steel

Other size as follow

Type Order no Weight(g) Price
DFM-10-5-P-A-GF 4154768 38 USD40-50
DFM-10-10-P-A-GF 4154769 45.5 USD40-50
DFM-10-15-P-A-GF 4154770 53.5 USD40-50
DFM-10-20-P-A-GF 4154799 60.5 USD40-50

Use in conveyor systems

4154769 Pneumatic Air Cylinders Guided Drive DFM-10-10-P-A-GF GTIN 4052568418052

Festo Core Range Solves the majority of your automation tasks.With the Festo Core Range, we have selected the most important products and functions from our broad product catalogue, and added the quickest delivery.

A wide range of products with excellent prices. Please hurry to me!
