Ball Screw Drive Electric Cylinder ESBF-BS-80-100-32P 574111 GTIN4052568222086

Name: Ball Screw Drive Electric Cylinder ESBFBS8010032P 574111 GTIN4052568222086
Brand: FESTO
Price: 1 USD

Quality Ball Screw Drive Electric Cylinder ESBF-BS-80-100-32P 574111 GTIN4052568222086 wholesale

Brand Name : FESTO

Model Number : ESBF-BS-80-100-32P

Place of Origin : China

MOQ : 1pc

Price : EXW USD1000-1500

Payment Terms : T/T, Western Union, Paypal

Supply Ability : 500 pcs per month

Delivery Time : 5-7working days

Packaging Details : Plastic bag, Carton

Type : ESBF-BS-80-100-32P

Part no : 574111

Brand : FESTO

Size : 80

Piston rod thread : M20x1.5

Weight : 7393 g

Contact Now

FESTO electric drive ESBF-BS-80-100-32P 574111 GTIN4052568222086

About product

1.Available with ball screw drive (size 32 … 100) or lead screw (size 32 … 50).

2.Ball screw: with three spindle pitches for selecting the optimal force-speed ratio.

3.Optional: high corrosion protection, degree of protection IP65, food-safe (see www.festo.com/certificates/ESBF), piston rod extension.

Advantage

1.High corrosion protection.

2.Degree of protection IP65.

3.Extended piston rod.

4.NSF-H1 lubricant for food & beverage industry applications.

5.Extensive accessories.

Technical Data

Size	80
Stroke	100 mm
Piston rod thread	M20x1.5
Spindle diameter	32 mm
Spindle pitch	32 mm/U
Based on standard	ISO 15552
Mounting position	optional
Piston-rod end	Male thread
Type of motor	Servo motor
Position detection	Via proximity switch
Design	Electric cylinder with ball screw
Spindle type	Ball screw
Symbol	00991941
Protection against torque/guide	With plain-bearing guide
Corrosion resistance class CRC	2 - Moderate corrosion stress
LABS (PWIS) conformity	VDMA24364 zone III
Storage temperature	-20°C-60°C
Degree of protection	IP40
Ambient temperature	0°C-60°C
Basic weight for 0 mm stroke	7393 g
Additional weight per 10 mm stroke	155 g
Type of mounting	Via female thread Or accessories
Interface code, actuator	D80
Note on materials	RoHS-compliant
Material cover	Cast aluminium, coated
Material piston rod	High-alloy stainless steel
Material screws	Galvanised steel
Material spindle nut	Rolled steel
Material cylinder barrel	Smooth-anodised wrought aluminium alloy

General technical data

There are many models. Please hurry to me!
