Name: Festo Front Panel Valve SV5M5B 11914 Pneumatic System Components
Brand: FESTO
Price: 1 USD

Brand Name : FESTO

Model Number : SV-5-M5-B

Place of Origin : China

MOQ : 1pc

Price : EXW USD20-40

Payment Terms : T/T, Western Union, Paypal

Supply Ability : 1000 pcs per month

Delivery Time : 7-10working days

Packaging Details : Plastic bag, Carton

Brand : FESTO

Part no : 11914

Type : SV-5-M5-B

Ambient temperature : -10°C-60°C

Pneumatic connection, port 1 : M5

Material housing : Polymer Brass

Contact Now

Festo Front panel valve SV-5-M5-B 11914 Pneumatic System Components

About product

1.Switches have several switching positions that can be alternated between as required.

2.Mushroom pushbuttons return to their initial switching position after they are actuated.

3.Key actuators can only be actuated using the key. The key can be removed in any switching position.

Technical Data

Valve function	5/2-way, monostable
Type of actuation	Manual
Standard nominal flow rate	95 l/min
Design	Poppet valve with spring return
Type of reset	Mechanical spring
Nominal size	2.3 mm
Sealing principle	Soft
Mounting position	optional
Type of piloting	Direct
Symbol	00991339
lap	Positive overlap
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Ambient temperature	-10°C-60°C
Product weight	53 g
Type of mounting	Front panel mounting With through-hole
Pneumatic connection, port 1	M5
Material seals	NBR
Material housing	Polymer Brass

Materials

There are many models . Please contact me!
