FESTO ISO Cylinder Pneumatic Air Cylinders DNC-80-500-PPV-A 163444

  • 1
  • 2

Brand Name : FESTO

Model Number : DNC-80-500-PPV-A

Place of Origin : China

MOQ : 1pc

Price : EXW USD80-100

Payment Terms : T/T, Western Union, Paypal

Supply Ability : 500 pcs per month

Delivery Time : 10-15working days

Packaging Details : plastic bag, carton，OPP bag

Type : DNC-80-500-PPV-A

Part no : 163444

Brand : FESTO

Mode of operation : Double-acting

Pneumatic connection : G3/8

Material seals : TPE-U(PU)

Contact Now

FESTO ISO cylinder DNC-80-500-PPV-A 163444 Pneumatic Air Cylinders

About product

Cushioning:Pneumatic cushioning, adjustable at both ends

Design:Piston Piston rod Profile barrel

Ambient temperature: -20°C-80°C

Basic weight for 0 mm stroke:2790 g

Note on materials: RoHS-compliant

Technical Data

Stroke 500mm
Piston diameter 80 mm
Piston rod thread M20x1.5
Cushioning Pneumatic cushioning, adjustable at both ends
Mounting position optional
Conforms to standard ISO 15552
Piston-rod end Male thread
Design Piston Piston rod Profile barrel
Position detection Via proximity switch
Symbol 00991235
Mode of operation Double-acting
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Ambient temperature -20°C-80°C
Cushioning length 32 mm
Basic weight for 0 mm stroke 2790 g
Additional weight per 10 mm stroke 106 g
Pneumatic connection G3/8
Note on materials RoHS-compliant
Material cove rDie-cast aluminium Coated
Material seals TPE-U(PU)
Material piston rod High-alloy steel
Material cylinder barrel Wrought aluminium alloy Smooth anodised

Delivery
1. If the products we have in store, we will send it out ASAP after payment.
2. If the products which were customized, we will complete the production within a specified period of time, and send it out the first time, we can promise it.
3. Also we can send by your delivery acount if you want.
4. We have a variety of ways to send goods, usually DHL, Fedex, TNT will be normal ways. If you require use of a courier, we can do it.

There are so many kinds. Please contact with me!
