Name: FESTO Compact cylinder ADVUL5050PA 156900 Pneumatic Air Cylinders
Brand: FESTO
Price: 1 USD

Brand Name : FESTO

Model Number : ADVUL-50-50-P-A

MOQ : 1pc

Price : EXW USD100-120

Payment Terms : T/T, Western Union, Paypal

Supply Ability : 800 pcs per month

Delivery Time : 7-10 working days

Packaging Details : plastic bag, carton，OPP bag

Type : ADVUL-50-50-P-A

Part no : 156900

Brand : FESTO

Ambient temperature : -20°C-80°C

Mode of operation : Double-acting

Corrosion resistance class CRC : 2 - Moderate corrosion stress

Contact Now

About product

Mounting position:optional

Symbol:00991737

Corrosion resistance class CRC:2 - Moderate corrosion stress

Color:Silver

Technical Data

Stroke	50 mm
Piston diameter	50 mm
Cushioning	Elastic cushioning rings/plates at both ends
Mounting position	optional
Design	Piston Piston rod
Position detection	Via proximity switch
Symbol	00991737
Variants	Piston rod at one end
Protection against torque/guide	Guide rod with yoke
Mode of operation	Double-acting
Corrosion resistance class CRC	2 - Moderate corrosion stress
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Ambient temperature	-20°C-80°C
Pneumatic connection	G1/8
Material collar screws	Galvanised steel
Material cover	Wrought aluminium alloy
Material dynamic seals	NBR TPE-U(PU)
Material piston rod	High-alloy steel
Material cylinder barrel	Wrought aluminium alloy

Dimensions – Basic cylinders

FESTO cylinder has good stability, quality, and long service life, making it your best choice.

FESTO Compact cylinder ADVUL-50-50-P-A 156900 Pneumatic Air Cylinders Images
