AEVU-25-5-P-A 156945 Festo Compact Cylinder Aluminum Double Acting Cylinder

Name: AEVU255PA 156945 Festo Compact Cylinder Aluminum Double Acting Cylinder
Brand: FESTO
Price: 1 USD

Quality AEVU-25-5-P-A 156945 Festo Compact Cylinder Aluminum Double Acting Cylinder wholesale

Brand Name : FESTO

Model Number : AEVU-25-5-P-A

Certification : CE

Place of Origin : China

MOQ : 1 piece

Price : Negotiation

Payment Terms : T/T , Western Union

Supply Ability : 1000 pcs

Delivery Time : within 1-30 working days after payment

Packaging Details : Plastic bags,Boxes, Cartons, Pallets,or according to customer's requirement

Model code : AEVU-25-5-P-A

Position : 20mm

Stroke : 25mm

Color : silvery

Body Material : Aluminum

Name : Cylinder

Contact Now

Festo Original Compact Cylinders AEVU-25-5-P-A 156945 aluminum Double-acting cylinder

1.Compact cylinder with standard dimension

2.More than the standard: Piston1/2"-2"

3.Innovative technology for maximum speeds
4. Flexible in use thanks to customized variants
5. Spare parts service

Compact cylinders for maximum productivity in confined spaces,combining innovative technology, high performance and reduced installation space requirements.

Typical Applications
Printing (Tension Control)

Semiconductor (spot welding machine, chip grinding)

Automation Control

Robot

Ordering Date

Piston(mm)	Stroke(mm)	Part No.	Type	Part No.	Type
12	5	156930	AEVU-12-5-P-A	156976	AEVU-12-5-A-P-A
12	10	156931	AEVU-12-10-P-A	156977	AEVU-12-10-A-P-A
16	5	156935	AEVU-16-5-P-A	156981	AEVU-16-5-A-P-A
	10	156936	AEVU-16-10-P-A	156982	AEVU-16-10-A-P-A
	15	156937	AEVU-16-15-P-A	156983	AEVU-16-15-A-P-A
	20	156938	AEVU-16-20-P-A	156984	AEVU-16-20-A-P-A
	25	156939	AEVU-16-25-P-A	156985	AEVU-16-25-A-P-A
20	5	156940	AEVU-20-12-P-A	156986	AEVU-20-12-A-P-A
	10	156941	AEVU-20-10-P-A	156987	AEVU-20-10-A-P-A
	15	156942	AEVU-20-15-P-A	156988	AEVU-20-15-A-P-A
	20	156943	AEVU-20-20-P-A	156989	AEVU-20-20-A-P-A
	25	156944	AEVU-20-25-P-A	156990	AEVU-20-25-A-P-A
25	5	156945	AEVU-25-5-P-A	156991	AEVU-25-5-A-P-A
	10	156946	AEVU-25-10-P-A	156992	AEVU-25-10-A-P-A
	15	156947	AEVU-25-15-P-A	156993	AEVU-25-15-A-P-A
	20	156948	AEVU-25-20-P-A	156994	AEVU-25-20-A-P-A
	25	156949	AEVU-25-25-P-A	156995	AEVU-25-25-A-P-A
32	5	156950	AEVU-32-5-P-A	156996	AEVU-32-5-A-P-A
	10	156951	AEVU-32-10-P-A	156997	AEVU-32-10-A-P-A
	15	156952	AEVU-32-15-P-A	156998	AEVU-32-15-A-P-A
	20	156953	AEVU-32-20-P-A	156999	AEVU-32-20-A-P-A
	25	156954	AEVU-32-25-P-A	157000	AEVU-32-25-A-P-A
40	5	156955	AEVU-40-5-P-A	157001	AEVU-40-5-A-P-A
	10	156956	AEVU-40-10-P-A	157002	AEVU-40-10-A-P-A
	15	156957	AEVU-40-15-P-A	157003	AEVU-40-15-A-P-A
	20	156958	AEVU-40-20-P-A	157004	AEVU-40-20-A-P-A
	25	156959	AEVU-40-25-P-A	157005	AEVU-40-25-A-P-A
50	10	156960	AEVU-50-10-P-A	157006	AEVU-50-10-A-P-A
	15	156961	AEVU-50-15-P-A	157007	AEVU-50-15-A-P-A
	20	156962	AEVU-50-20-P-A	157008	AEVU-50-20-A-P-A
	25	156963	AEVU-50-25-P-A	157009	AEVU-50-25-A-P-A
63	10	156964	AEVU-63-10-P-A	157010	AEVU-63-10-A-P-A
	15	156965	AEVU-63-15-P-A	157011	AEVU-63-15-A-P-A
	20	156966	AEVU-63-20-P-A	157012	AEVU-63-20-A-P-A
	25	156967	AEVU-63-25-P-A	157013	AEVU-63-25-A-P-A
80	10	156968	AEVU-80-10-P-A	157014	AEVU-80-10-A-P-A
	15	156969	AEVU-80-15-P-A	157015	AEVU-80-15-A-P-A
	20	156970	AEVU-80-20-P-A	157016	AEVU-80-20-A-P-A
	25	156971	AEVU-80-25-P-A	157017	AEVU-80-25-A-P-A
100	10	156972	AEVU-100-10-P-A	157018	AEVU-100-10-A-P-A
	15	156973	AEVU-100-15-P-A	157019	AEVU-100-15-A-P-A
	20	156974	AEVU-100-20-P-A	157020	AEVU-100-20-A-P-A
	25	156975	AEVU-100-25-P-A	157021	AEVU-100-25-A-P-A

AEVU-25-5-P-A 156945 Festo Compact Cylinder Aluminum Double Acting Cylinder

Warranty
All item Comes with Basic 3 Month Sellers Warranty, if item defective in 3 Month, We will offer replacement without extra Charger(including shipping fee)After we Receive the Defective item.

If item Defective after 3 Month, Buyers can still send it back, We will contact suppliers or Manufactory for Warranty. Buyers Might Need to pay the Shipping fee For resend the replaced item.
